Hyundai Diesel Generator - 28kW (Single Phase)
Heavy-duty 28kW single-phase diesel generator for demanding commercial applications. Designed for extended runtime and reliable performance.
Hyundai DHY28KSEm 1500rpm 28kVA Single Phase Diesel Generator
The DHY28KSEm is a single phase diesel generator which has a maximum output of 28kVA/29kW. Our largest 230v single phase generator, this model will power larger domestic properties and offices, providing vital reassurance in the event of a power failure. It is a powerful choice of diesel generator for both emergency standby backup, just like it's three-phase twin model the DHY28KSE. However, it can also be used as the sole supply of power if required and can be run daily without failure due to it's increased lifespan.
With a slow running Hyundai 1500rpm engine which typically runs at half the rate of any normal diesel generator, extending the lifespan of this generator. The DHY28KSEm's exterior housing is designed to keep ambient noise levels as low as possible as well as protecting the internals from the worst of the weather.
Inside the rigged, weather-proof canopy, there is a four cylinder, 4-stroke water- cooled, diesel engine which runs at very low rate of the revs.
For detailed technical information on the Hyundai DHY28KSEm 1500rpm 28kVA Diesel Generator, please click on the Specifications tab above.
Specifications
|
General
|
Dimensions (mm)
|
Length 2200 x Width 950 x Height 1240
|
|
Rated Power (kW/kVA)
|
25
|
|
MAX. Power (kW/kVA)
|
27.5/27.5
|
|
Frequency
|
50
|
|
Voltage(s)
|
230
|
|
Controller
|
IL-NT MRS10
|
|
ATS Port
|
IL-NT MRS10
|
|
Battery (Ah)
|
1x12V-60Ah
|
|
Fuel Capacity
|
93
|
|
Cooling Fluid Volume (L)
|
10
|
|
Fuel Consumption (l/h 50/100% loading)
|
5.2/9.3
|
|
Engine
|
DG4102
|
|
Power Output (kW/1500rpm)
|
32
|
|
Rotate Speed
|
1500 RPM
|
|
Speed Regulation
|
MECHANICAL
|
|
Displacement (cc)
|
3857
|
|
Oil Capacity (L)
|
15
|
|
Alternator
|
AVR
|
|
Power Factor (Cosφ)
|
1
|
|
Low Oil Pressure
|
Yes
|
|
Block On Startup
|
Yes
|
|
Low Battery
|
Yes
|
|
Low Oil Level
|
Yes
|
|
Low Running On Engine
|
Yes
|
|
Emergency Stop
|
Yes
|
|
Noise @ 1m
|
92
|
|
Noise @ 7m
|
65
|
|
Capacity (units/container)
|
2220 x 950 x 1300
|
