Hyundai DHY22KSEm 1500rpm 22kVA Single Phase Diesel Generator
Manufacturer part number: DHY22KSEm
Manufacturer: HYUNDAI
Call for pricing

Hyundai DHY22KSEm 1500rpm 22kVA Single Phase Diesel Generator





This diesel generator would be suitable for powering a large home or office, or a number of site cabins on a construction site, using it's powerful 22kVA output with a single phase supply. Running at 1500rpm it is a very low stressed generator and has a very long lifespan, as the rev rate of the engine is typically half that of a conventional diesel generator of this size.

All standard Hyundai 1500rpm diesel generators above 15kw are designed to be used as stationary generators for standby or prime power supply. The DHY22KSEm Diesel Generator is part of the Hyundai silenced range, where due to the weatherproof acoustic body, large exhaust and the the economical engine, the noise levels whilst running are kept to a minimum, making for a very quiet run considering the size and output.

As with other models in the Hyundai range, the brushless AVR alternator produces a smooth power output, has a digital control panel, offering accurate overload and engine protection and includes a large base-level fuel tank, which is easily filled up from the outer shell of the generator, and makes for an extended run due to it's volume.

Specifications

General

Dimensions (mm)

Length 2200 x Width 950 x Height 1240

Rated Power (kW/kVA)

20/20

MAX. Power (kW/kVA)

22/22

Frequency

50

Controller

IL-NT MRS10

ATS Port

Included

Battery (Ah)

1x12V-54Ah

Fuel Capacity

93

Cooling Fluid Volume (L)

10

Fuel Consumption (l/h 50/100% loading)

4.5 / 7.7

Engine

DG4100

Power Output (kW/1500rpm)

27

Rotate Speed

1500 RPM

Speed Regulation

MECHANICAL

Displacement (cc)

3298

Oil Capacity (L)

15

Power Factor (Cosφ)

1

Voltage Regulation

AVR / BRUSHLESS

Low Oil Pressure

Yes

Block On Startup

Yes

Low Battery

Yes

Low Oil Level

Yes

Low Running On Engine

Yes

Emergency Stop

Yes

N.G. (kg.)

880

Noise @ 1m

92

Noise @ 7m

65



Hyundai DHY22KSEm 1500rpm 22kVA Single Phase Diesel Generator





This diesel generator would be suitable for powering a large home or office, or a number of site cabins on a construction site, using it's powerful 22kVA output with a single phase supply. Running at 1500rpm it is a very low stressed generator and has a very long lifespan, as the rev rate of the engine is typically half that of a conventional diesel generator of this size.

All standard Hyundai 1500rpm diesel generators above 15kw are designed to be used as stationary generators for standby or prime power supply. The DHY22KSEm Diesel Generator is part of the Hyundai silenced range, where due to the weatherproof acoustic body, large exhaust and the the economical engine, the noise levels whilst running are kept to a minimum, making for a very quiet run considering the size and output.

As with other models in the Hyundai range, the brushless AVR alternator produces a smooth power output, has a digital control panel, offering accurate overload and engine protection and includes a large base-level fuel tank, which is easily filled up from the outer shell of the generator, and makes for an extended run due to it's volume.

Specifications

General

Dimensions (mm)

Length 2200 x Width 950 x Height 1240

Rated Power (kW/kVA)

20/20

MAX. Power (kW/kVA)

22/22

Frequency

50

Controller

IL-NT MRS10

ATS Port

Included

Battery (Ah)

1x12V-54Ah

Fuel Capacity

93

Cooling Fluid Volume (L)

10

Fuel Consumption (l/h 50/100% loading)

4.5 / 7.7

Engine

DG4100

Power Output (kW/1500rpm)

27

Rotate Speed

1500 RPM

Speed Regulation

MECHANICAL

Displacement (cc)

3298

Oil Capacity (L)

15

Power Factor (Cosφ)

1

Voltage Regulation

AVR / BRUSHLESS

Low Oil Pressure

Yes

Block On Startup

Yes

Low Battery

Yes

Low Oil Level

Yes

Low Running On Engine

Yes

Emergency Stop

Yes

N.G. (kg.)

880

Noise @ 1m

92

Noise @ 7m

65



Products specifications
Component Manufacture HYUNDAI
Requirement Residential Single Phase 240v
Fuel Diesel
KVA Rating 22 Kva
Amp Rating 90 Amp
Frame Arrangement Acoustic Canopy
Products specifications
Component Manufacture HYUNDAI
Requirement Residential Single Phase 240v
Fuel Diesel
KVA Rating 22 Kva
Amp Rating 90 Amp
Frame Arrangement Acoustic Canopy
