Picture of ABB Changeover ATS - Single Phase

ABB Changeover ATS - Single Phase

Professional ABB single-phase changeover automatic transfer switches available in multiple current ratings. Perfect for applications requiring automatic switching between two utility power sources.
Manufacturer: ABB

Product Specification for Mains to Generator Operation ABB Single Phase

1) 2 x 4 Pole AC1 Rated Contactors, Electrically & Mechanically Interlocked "break before make"

2) Phase Failure Relay For Mains Monitoring

3) Mains (Utility) Delay On Load Timer ( Pre Set 10sec )( Adjustable 0.3 Sec  30 Hrs )

4) Generator  Delay On Load Timer ( Pre Set 30sec ) ( Adjustable 0.3 Sec 30 Hrs )

5) 10 Amp Mains L1- 240v A/c Auxiliary Supply For ( B/Charger / W/Heater)

6) Set Rated Fuses for control circuit

7) Mains On Load Volt Free Contact ( For BMS )

8) Generator On Load Volt Free Contact ( For BMS )

9) Set Volt Free Contacts for remote Start Facility ( 2 Wire Start )

10) Mounted Within an all Steel Enclosure, with Top & Bottom Removable Gland Plates.

IP65 Rated RAL7032 With Lockable Door 1 Key Supplied & Wall Mounting Brackets


LED Indication
Mains Available (GREEN), Mains On Load (RED)
Generator Available (GREEN), Generator On Load (AMBER)

 We have Contactor Options from

LOVATO

TERASAKI

ICG

If you require different manufacturer, please contact and we will add these to our range.

ADDITIONAL OPTIONS IF REQUIRED- IF NOT SHOWN PLEASE CALL FOR PRICING

Auto Test Facility Switch With 2 Keys, Primary Mains Failure Simulation

Deep-Sea - 12v & 24V Dc Battery Charger

Modbus RS485 Connections Available

Digital Metering For Voltage / Current  - Including Current Transformers

Picture of Changeover ATS - 45 Amp ABB Single Phase

Changeover ATS - 45 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using Only UK Suppliers. They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB345
£533.29 incl tax
Picture of Changeover ATS - 60 Amp ABB Single Phase

Changeover ATS - 60 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be a diesel generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Diesel Generators and Petrol Generating Sets, Ups Equipment and/or Power Utilities.
SKU: ABB360
£588.76 incl tax
Picture of Changeover ATS - 100 Amp ABB Single Phase

Changeover ATS - 100 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Generators and Generating Sets, Ups Equipment and/or Power Utilities.
SKU: ABB3100
£675.84 incl tax
Picture of Changeover ATS - 25 Amp ABB Single Phase

Changeover ATS - 25 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Generators and Generating Sets, Ups Equipment and/or Power Utilities.
SKU: BPGATS25
£492.87 incl tax
Picture of Changeover ATS - 160 Amp ABB Single Phase

Changeover ATS - 160 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Generators and Generating Sets, Ups Equipment and/or Power Utilities.
SKU: ABB-3160
£1,063.55 incl tax
Picture of Changeover ATS - 160 Amp ABB Single Phase

Changeover ATS - 160 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Generators and Generating Sets, Ups Equipment and/or Power Utilities.
SKU: ABB3160
£862.09 incl tax
Picture of Changeover ATS - 125 Amp ABB Single Phase

Changeover ATS - 125 Amp ABB Single Phase

Automatic Transfer Switching ATS & AMF Emergency power is transferred automatically from one supply to another if it be generator or 2nd mains supply via one or more load circuits, either manual or motorized. When the original supply is restored, the system automatically changes back. The stand-by generator will eventually shut down after a short cooling down period. We offer a full range of automatic and manual change over switches, also known as changeover & bypass switches with sizes from 16-2500 Amps in three and four pole versions. Our changeover switches are suitable for any power supply system application requiring an uninterrupted supply of power from Generators and Generating Sets, Ups Equipment and/or Power Utilities.
SKU: ABB3125
£707.09 incl tax
Picture of Changeover ATS - 125 Amp ABB Single Phase

Changeover ATS - 125 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB3125MG
Delivery date: 3-5 days
£977.17 incl tax
Picture of Changeover ATS - 160 Amp ABB Single Phase

Changeover ATS - 160 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB3160MG
Call for pricing
Picture of Changeover ATS - 25 Amp ABB Single Phase

Changeover ATS - 25 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB325MG
£631.58 incl tax
Picture of Changeover ATS - 100 Amp ABB Single Phase

Changeover ATS - 100 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using Only UK Suppliers. They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB3100MG
Delivery date: 3-5 days
£863.50 incl tax
Picture of Changeover ATS - 55 Amp ABB Single Phase

Changeover ATS - 55 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB355MG
Delivery date: 3-5 days
£791.08 incl tax
Picture of Changeover ATS - ABB 70 Amp Single Phase

Changeover ATS - ABB 70 Amp Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB370MG
Delivery date: 3-5 days
£844.25 incl tax
Picture of Changeover ATS - 45 Amp ABB Single Phase

Changeover ATS - 45 Amp ABB Single Phase

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB345MG
Delivery date: 3-5 days
£721.42 incl tax
Picture of Changeover ATS - 30 Amp ABB Single Phase N

Changeover ATS - 30 Amp ABB Single Phase N

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB330MG
Delivery date: 3-5 days
£645.33 incl tax
Picture of Changeover ATS - 25 Amp ABB Single Phase N

Changeover ATS - 25 Amp ABB Single Phase N

Here At Blades Power, we have a full range of Automatic Transfer Switches Manufactured In House Using . They are built to the highest standard, all panels are fully tested and issued with a serial No. Every Panel is dispatched with a copy of the Electrical Schematic and test report + All Datasheets for each electrical internal part.
SKU: ABB325MG
£631.58 incl tax

Products specifications

Attribute name Attribute value
Electrical ratings
Rated current (A) 25 A, 30 A, 45 A, 55 A, 70 A, 100 A, 125 A, 160 A
