Product Details
Product Specification for Mains to Generator Operation 3 Phase N
1) 2 x 4 Pole AC1 Rated Contactors, Electrically & Mechanically Interlocked "break before make"
2) Phase Failure Relay For Mains Monitoring
3) Mains (Utility) Delay On Load Timer ( Pre Set 10sec )( Adjustable 0.3 Sec 30 Hrs )
4) Generator Delay On Load Timer ( Pre Set 30sec ) ( Adjustable 0.3 Sec 30 Hrs )
5) 10 Amp Mains L1- 240v A/c Auxiliary Supply For ( B/Charger / W/Heater)
6) Set Rated Fuses for the control circuit
7) Mains On Load Volt Free Contact ( For BMS )
8) Generator On Load Volt Free Contact ( For BMS )
9) Set Volt Free Contacts for remote Start Facility ( 2 Wire Start )
10) Mounted within an all-steel enclosure, with top and bottom removable gland plates.
IP65 Rated RAL7032 With Lockable Door 1 Key Supplied & Wall Mounting Brackets
LED Indication
Mains Available (GREEN), Mains On Load (RED)
Generator Available (GREEN), Generator On Load (AMBER)
We also have alternative Contactor Options from
LOVATO
TERASAKI
ICG
If you require different manufacture, please contact and we will add these to our range.
ADDITIONAL OPTIONS IF REQUIRED- IF NOT SHOWN PLEASE CALL FOR PRICING
Auto Test Facility Switch With 2 Keys, Primary Mains Failure simulation
Deep-Sea - 12v & 24V Dc Battery Charger
Modbus RS485 Connections Available
Digital Metering For Voltage / Current - Including Current Transformers
